BT100

Specifications

Supply Voltage:

10.0 to 30.0 VDC 0.015 amps max.

Data Input:

NMEA 0183.

Operating temperature:

0 to 50 deg Celsius ( 32 to 122 deg Fahrenheit).

Size:

50 x 35 x 30 mm (2 x 1.4 x 1.2 inch)

Operating Range:

Up to 30M (98 Feet)

Module Name:

JDY-33-SPP

Pairing Code:

1234
